I have talked about the difference between a five-axis cnc router and a four-axis cnc router. Don’t worry, the cnc router manufacturer will tell you about the circuit design of the control system of the four-axis woodworking cnc router. I believe you will gain more.
Shandong cnc router manufacturers conduct research on the specific components used in the control system of the four-axis cnc router based on the overall design of the four-axis cnc router control system.
①The power supply adopts 220V AC power supply, and the components of the distribution box are protected by the fuse, that is, the power supply of the control system can be automatically cut off in the event of a short circuit or excessive current;
②The three button switches (total stop button, servo system button and computer mainframe power button) are controlled by 220V alternating current to control the total power supply, servo system power supply and PC power supply respectively, and enable different machine functions according to different processing needs;
③A TDK filter is installed between the servo system button and the servo drive to prevent the entry of high-frequency noise from the external power supply, reduce the interference to the system servo, and ensure the stability of the work;
④Because the motion control card EX4A2 terminal board needs independent power supply, a 24V switching power supply is used;
⑤The X, Y, Z axis drivers are connected to the X, Y, Z axis interfaces of the control card EX4A2 terminal board, and the A axis drivers are connected to the A axis interface of the motion control card EX4A2 terminal board. They all have different interface terminals;
⑥ The spindle frequency converter is connected to the pulse interface of the control card EX4A2 terminal board to realize the pulse transmission to the electric spindle;
⑦The drive is connected to the corresponding motor, and the inverter is connected to the corresponding electric spindle;
⑧ The sensor is connected to the X, Y, Z axis interface of the control card EX4A2 terminal board to control the limit position of the machine tool. The cnc router manufacturer pointed out that the circuit can also select different components according to the accuracy requirements of different machine tools.
As a well-known cnc router manufacturer in the market, BCAM tells you the overall design and circuit design of the four-axis woodworking cnc router control system through two articles. I believe everyone is already familiar with the control system of the four-axis woodworking cnc router. The control operation of the cnc router should also be more proficient, if you have any questions, you can directly communicate with our online customer service, BCAM will serve you wholeheartedly.
